PlayerController: the hub

Central MonoBehaviour. Auto-finds every sub-component in Awake if you leave them unassigned, so external code only needs one reference.

Subsystem accessors

Property	Type	Subsystem
`Settings`	`PlayerSettings`	global config asset
`Input`	`PlayerInputHandler`	input state
`Locomotion`	`PlayerLocomotion`	movement & physics
`CameraController`	`PlayerCameraController`	FPS camera
`AnimatorController`	`PlayerAnimatorController`	animation + item layers
`HeadIK`	`PlayerHeadIK`	head look-at IK
`HandIK`	`PlayerHandIK`	hand IK
`SpineStabilizer`	`PlayerSpineStabilizer`	spine yaw
`HandItemSocket`	`HandItemSocket`	item equip

State (read-only)

Member	Type	Notes
`IsGrounded`	read-only state
`IsSprinting`	read-only state
`MoveInput`	read-only state
`LookInput`	read-only state
`FlashlightTriggered`	read-only state
`CurrentSpeed`	read-only state
`MaxSpeed`	read-only state

Control methods (menus / cutscenes / pausing):

Member	Signature	Notes
`SetInputEnabled`	`SetInputEnabled(bool)`
`SetMovementEnabled`	`SetMovementEnabled(bool)`
`SetCameraEnabled`	`SetCameraEnabled(bool)`
`SetHeadIKEnabled`	`SetHeadIKEnabled(bool)`
`SetHandIKEnabled`	`SetHandIKEnabled(bool)`
`SetSpineStabilizationEnabled`	`SetSpineStabilizationEnabled(bool)`
`SetCursorLocked`	`SetCursorLocked(bool)`
`EnableAllControls`	`EnableAllControls()`	resume gameplay
`DisableAllControls`	`DisableAllControls()`	enter cutscene / menu

var player = GetComponent<PlayerController>();
player.DisableAllControls();   // enter cutscene / menu
// ...
player.EnableAllControls();    // resume gameplay

Configuration: PlayerSettings

ScriptableObject (Create ▸ Player ▸ Settings). Referenced by most components, so it's the single place to tune feel. beginnerMode toggles a simplified inspector view.

Member	Type	Notes
`beginnerMode`	`bool`	When enabled, the Inspector will show a simplified view for beginners. (default: true)
`walkSpeed`	`float`	Walking speed in units per second. (default: 3.0f)
`sprintSpeed`	`float`	Sprinting speed in units per second. (default: 6.0f)
`crouchSpeed`	`float`	Movement speed while crouching in units per second. (default: 1.5f)
`crouchHeight`	`float`	CharacterController height while crouching. (default: 1.0f)
`standHeight`	`float`	CharacterController height while standing. (default: 2.0f)
`crouchTransitionSpeed`	`float`	Speed of crouch/stand transition. (default: 8f)
`jumpHeight`	`float`	Jump height in units. (default: 1.2f)
`gravity`	`float`	Gravity force (should be negative). (default: -15f)
`groundCheckDistance`	`float`	Distance to check for ground below player. (default: 0.2f)
`groundedVelocityReset`	`float`	Velocity applied when grounded to keep player grounded. (default: -2f)
`inputDeadzone`	`float`	Minimum input magnitude to register movement. (default: 0.01f)
`animationSmoothTime`	`float`	Time to smooth animation parameter changes. (default: 0.1f)
`sprintAnimMultiplier`	`float`	Animation speed multiplier when sprinting. (default: 1.5f)
`defaultHeadHeight`	`float`	Default head height when no head bone is available. (default: 1.6f)
`lookTargetDistance`	`float`	Distance to place look target in front of player. (default: 2f)
`cameraFallbackHeadHeight`	`float`	Fallback head height when head bone is not assigned. (default: 1.7f)
`verticalLookLimit`	`float`	Maximum vertical look angle for the camera. (default: 80f)
`handVerticalLimitUpper/Lower`	`float`	Maximum vertical look angle for the hand IK tracking when looking UP; Maximum vertical look angle for the hand IK tracking when looking DOWN. (default: 45f / 45f)
`enableSpineStabilization`	`bool`	Enable spine stabilization logic. (default: true)
`spineStiffness`	`float`	Weight of stabilization. (default: 1.0f)
`spineDamping`	`float`	Smoothing speed. (default: 10f)
`lowerSpineWeight`	`float`	Rotation weight for lower spine. (default: 0.3f)
`middleSpineWeight`	`float`	Rotation weight for middle spine. (default: 0.3f)
`upperSpineWeight`	`float`	Rotation weight for upper spine. (default: 0.4f)

Input: PlayerInputHandler

Reads the Unity Input System asset (inputActions, actionMapName = "Player").

Per-frame state (read-only)

Member	Type	Notes
`MoveInput`	`Vector2`	Current movement input vector (X = Strafe, Y = Forward), normalized between -1 and 1.
`LookInput`	`Vector2`	Current look input vector (X = Horizontal, Y = Vertical) from mouse/joystick.
`IsSprinting`	`bool`	Whether the sprint button is currently held.
`JumpTriggered`	`bool`	Whether a jump was triggered this frame; true for the single frame jump is pressed.
`IsCrouching`	`bool`	Whether the player is in the crouch state (toggled on each press).
`FlashlightTriggered`	`bool`	Whether the flashlight was toggled this frame; true for the single frame it is pressed.

Methods

Member	Signature	Notes
`LockCursor`	`LockCursor()`	Locks the cursor for first-person gameplay (sets `Cursor.lockState` to Locked, hides cursor).
`UnlockCursor`	`UnlockCursor()`	Unlocks the cursor for UI interaction (sets `Cursor.lockState` to None, shows cursor).

Player action map (`FBInputActions`)

Move
Look
Attack
Interact
Crouch
Jump
Previous
Next
Sprint
Flashlight

Locomotion: PlayerLocomotion

[RequireComponent(typeof(CharacterController))].

Configurable fields

Member	Type	Notes
`walkSpeed`	`float`	Horizontal movement speed while walking. (default: 3.0f)
`sprintSpeed`	`float`	Horizontal movement speed while sprinting. (default: 6.0f)
`jumpHeight`	`float`	Vertical height of a single jump. (default: 1.2f)
`gravity`	`float`	Gravity force applied to the player (negative value). (default: -15f)
`crouchSpeed`	`float`	Horizontal movement speed while crouching. (default: 1.5f)
`crouchHeight`	`float`	CharacterController height when fully crouched. (default: 1.0f)
`standHeight`	`float`	CharacterController height when standing. (default: 2.0f)
`crouchTransitionSpeed`	`float`	Speed of height interpolation between states. (default: 8f)
`groundCheckDistance`	`float`	Distance below feet to check for ground. (default: 0.2f)
`groundLayers`	`LayerMask`	Layers to consider as ground. (default: ~0)
`inputDeadzone`	`float`	Minimum input magnitude to trigger movement. (default: 0.01f)

State

Member	Type	Notes
`IsGrounded`	`bool`	True if the player is currently touching the ground (CharacterController + raycast fallback).
`IsSprinting`	`bool`	True if the player is currently sprinting; only possible when grounded and not crouching.
`CurrentSpeed`	`float`	The current horizontal speed of the player in units per second.
`MaxSpeed`	`float`	The theoretical maximum speed in the current state (crouch/walk/sprint).

Fires the locomotion events listed below.

Camera: PlayerCameraController

Cinemachine-based.

Configurable

Member	Type	Notes
`eyeOffset`	`Vector3`	Offset from head bone position while standing. (default: (0, 0.05, 0.1))
`crouchEyeOffset`	`Vector3`	Offset from head bone position while crouching. (default: (0, 0.05, 0.05))
`lookSensitivity`	`float`	Mouse sensitivity multiplier. (default: 0.1f)
`verticalLookLimit`	`float`	Maximum vertical look angle (degrees). (default: 80f)

Public API

Member	Type / Signature	Notes
`CameraTarget`	`Transform`	The actual transform the Cinemachine camera follows and looks at.
`Pitch`	`float`	Current vertical look angle in degrees (used by Animation Rigging).
`Yaw`	`float`	Current horizontal look angle in degrees.
`GetLookAngles`	`GetLookAngles() → Vector2`	Gets the current look direction as a Vector2 (X = Yaw, Y = Pitch).
`SetLookDirection`	`SetLookDirection(float yaw, float pitch)`	Sets the look direction programmatically (useful for respawning, cutscenes, etc.).
`SyncCameraTargetToHead`	`SyncCameraTargetToHead()`	Syncs the camera target position to the animated head bone; called in LateUpdate; external IK systems may call it manually.
`SetVerticalLimitOverride`	`SetVerticalLimitOverride(float upper, float lower)`	Sets the vertical limit override for asymmetric look limits (used by item IK data).

Items

HandItemSocket: canonical equip event source

The single owner of equip/unequip events.

Properties

Member	Type	Notes
`CurrentItem`	`GameObject`	The currently equipped item.
`HasItem`	`bool`	Whether an item is currently equipped.
`Socket`	`Transform`	The socket transform where items are attached.
`Locomotion`	`PlayerLocomotion`	The player locomotion system (used for crouch offsets).

Methods

Member	Signature	Notes
`AttachItem`	`AttachItem(GameObject, Vector3? pos, Vector3? rot)`	Attaches an item to the hand socket with optional position/rotation offsets.
`AttachItem`	`AttachItem(GameObject, ItemAttachmentData)`	Attaches an item using an ItemAttachmentData configuration (offsets + animation info).
`EquipFromContainer`	`EquipFromContainer(GameObject, int slotIndex = -1)`	Equips an item from a container; activates it and applies ItemHoldData offsets, animator layer, and IK.
`UseCurrentItem`	`UseCurrentItem()`	triggered by the `Flashlight/Use` input; fires the `OnUse` event on the equipped item's ItemHoldData.

Events: see Event API.

ItemContainer: orchestration

Manages a list of items and equips them through the socket (it no longer emits its own equip events).

Properties

Member	Type	Notes
`CurrentItem`	`GameObject`	The currently equipped item, or null if none.
`HasEquippedItem`	`bool`	Whether an item is currently equipped.
`CurrentIndex`	`int`	The index of the currently equipped item, or -1 if none.
`ItemCount`	`int`	Number of items in the container.
`HandSocket`	`HandItemSocket`	The hand socket this container equips items through; subscribe to its canonical item events (e.g. `ItemEquipped`).

Methods

Member	Signature	Notes
`EquipItem`	`EquipItem(int)`	Equips an item by index in the items list.
`EquipItemById`	`EquipItemById(string)`	Equips an item by its unique ID defined in ItemHoldData.
`EquipItem`	`EquipItem(GameObject)`	Equips a specific item GameObject (must be in the items list).
`UnequipCurrent`	`UnequipCurrent()`	Unequips the currently equipped item.
`EquipNext`	`EquipNext()`	Cycles to the next item in the container (wraps around to index 0).
`EquipPrevious`	`EquipPrevious()`	Cycles to the previous item in the container (wraps around to the last item).
`GetItem`	`GetItem(int)`	Gets an item by index without equipping it.
`GetItemById`	`GetItemById(string)`	Gets an item GameObject by its unique ID defined in ItemHoldData.
`AddItem`	`AddItem(GameObject)`	Adds an item to the container's list (deactivated until equipped); fires `OnContainerChanged`.
`RemoveItem`	`RemoveItem(GameObject) → bool`	Removes an item from the container; unequips it first if currently equipped; fires `OnContainerChanged`; returns true if removed.

Event

Member	Type	Notes
`OnContainerChanged`	`UnityEvent`	fires when the item list itself changes: add/remove

ItemHoldData: per-item config & reactions

Attach to item GameObjects.

Member	Type	Notes
`itemId`	`string`	identity; unique identifier used to equip items via code or ID-based systems. (default: "NewItem")
`OnEquip`	`UnityEvent`	item-local event; fires alongside the system events
`OnUnequip`	`UnityEvent`	item-local event; fires alongside the system events
`OnUse`	`UnityEvent`	item-local event; fires alongside the system events
`attachmentData`	`ItemAttachmentData`	config
`worldItemPrefab`	`GameObject`	config; should carry a `WorldItem` component; prefab to spawn when this item is dropped
`ItemId`	`string`	property; unique identifier for this item
`AttachmentData`	`ItemAttachmentData`	property; configuration for how this item is attached and held
`WorldItemPrefab`	`GameObject`	property; prefab used when dropping this item into the world

ItemAttachmentData: hold & IK config

[Serializable].

Member	Type	Notes
`animatorLayerIndex`	`int`	The index of the override animation layer for this item; used to play specific hold/use animations. (default: 1)
`holdStyle`	`OneHandedRight` \| `TwoHanded`	Defines if the item is held with one hand or two hands. (default: OneHandedRight)
`gripPositionOffset`	`Vector3`	Local position offset of the item mesh relative to the hand socket transform. (default: Vector3.zero)
`gripRotationOffset`	`Vector3`	Local rotation offset of the item mesh relative to the hand socket transform (Euler angles). (default: Vector3.zero)
`debugMode`	`bool`	editor-only; tune live in the editor; when enabled, offsets update in real-time (field lives on `ItemHoldData`). (default: false)
`tuneGripMode`	`bool`	editor-only; tune live in the editor; when enabled, transform changes are captured into the grip offsets (field lives on `ItemHoldData`). (default: false)

Plus standing/crouching hand and elbow IK overrides.

ItemIKPreset: share IK config

ScriptableObject (Create ▸ Player ▸ Item IK Preset).

Member	Signature	Notes
`CaptureFromScene`	`CaptureFromScene()`	context menu; copies IK config between items
`ApplyToScene`	`ApplyToScene()`	context menu; copies IK config between items

Event API: PlayerEventAPI

Three complementary mechanisms, each fired once per transition from a single canonical chokepoint:

Mechanism	For
C# `event Action<TArgs>`	code subscribers (struct args, no per-call allocation)
`UnityEvent`	Inspector / no-code wiring
Listener interfaces	full extension / structured contract; auto-discovered

Event payloads

ItemEquipArgs: Item (GameObject), SlotIndex (int, -1 if equipped outside a container), HoldData (ItemHoldData), FromContainer (bool).
LandArgs: ImpactVelocity (float), FallDistance (float).

Item events: `HandItemSocket`

C# events

Member	Type	Notes
`ItemEquipped`	`event Action<ItemEquipArgs>`
`ItemUnequipped`	`event Action<ItemEquipArgs>`

Inspector

Member	Type	Notes
`OnItemEquipped`	`ItemEvent : UnityEvent<GameObject>`
`OnItemUnequipped`	`ItemEvent : UnityEvent<GameObject>`

Fire for every socket-backed equip/unequip (manual attach, container equip, detach).

Locomotion events: `PlayerLocomotion`

C# events

Member	Type	Notes
`Jumped`	`Action<LandArgs>`
`Landed`	`Action<LandArgs>`
`CrouchStarted`	`Action`	fires when crouch begins
`CrouchEnded`	`Action`	fires when crouch ends
`SprintStarted`	`Action`	fires when sprint begins
`SprintEnded`	`Action`	fires when sprint ends
`GroundedChanged`	`Action<bool>`

Inspector UnityEvent mirrors

Member	Notes
`OnJumped`
`OnLanded`
`OnCrouchStarted`
`OnCrouchEnded`
`OnSprintStarted`
`OnSprintEnded`

Listener interfaces

Implement on any MonoBehaviour under the player; it's found at startup automatically. Unhandled methods are no-ops; override only what you need.

using Player;

public class MyListener : MonoBehaviour, IItemEventListener, ILocomotionEventListener
{
    public void OnItemEquipped(ItemEquipArgs args) => Debug.Log($"equipped {args.Item.name}");
    public void OnItemUnequipped(ItemEquipArgs args) { }
    public void OnLanded(LandArgs args) => Debug.Log($"landed at {args.ImpactVelocity}");
    // OnJumped, OnCrouchStarted/Ended, OnSprintStarted/Ended, OnGroundedChanged default to no-op
}

Runtime-added listeners:

Member	Notes
`locomotion.RegisterListener(ILocomotionEventListener)`	register a locomotion listener
`socket.RegisterListener(IItemEventListener)`	register an item listener
`UnregisterListener(...)`	matching unregister on both

Subscribe in code

player.Locomotion.Jumped += () => Debug.Log("jumped");
player.HandItemSocket.ItemEquipped += args =>
    Debug.Log($"equipped {args.Item.name} from slot {args.SlotIndex}");

FPCutter: FPCutterController

Hides body parts in first person (default: Head) while keeping shadow casting. Generated by the FPCutter Wizard.

Methods

Member	Signature	Notes
`SetFirstPerson`	`SetFirstPerson()`
`SetThirdPerson`	`SetThirdPerson()`
`HidePart`	`HidePart(BodyPart)`
`ShowPart`	`ShowPart(BodyPart)`

Config

Member	Type	Notes
`HideInFirstPerson`	`List<BodyPart>`
`invisibleMaterial`	`Material`	uses the `FPCutter_Invisible` shader

The BodyPart enum is defined in FPCutterData.

Animator: PlayerAnimatorController

Drives animator parameters and item animation layers.

Member	Type / Signature	Notes
`SetItemLayer`	`SetItemLayer(int)`
`SetFlashlightActive`	`SetFlashlightActive(bool)`
`ToggleFlashlight`	`ToggleFlashlight()`
`TriggerAnimation`	`TriggerAnimation(string)`
`GetAnimator`	`GetAnimator() → Animator`
`IsFlashlightActive`	`property`

Procedural IK (advanced)

Tuned by the Setup Wizard; adjust only for advanced customization.

PlayerHeadIK

Member	Type / Signature	Notes
`Weight`	`get/set`
`SetWeight`	`SetWeight(float)`
`SetWeights`	`SetWeights(body, head, eyes, clamp)`
`SetEnabled`	`SetEnabled(bool)`

PlayerHandIK

Member	Type / Signature	Notes
`IKPositionWeight`	`get/set`
`SetEnabled`	`SetEnabled(bool)`

PlayerSpineStabilizer

[RequireComponent(typeof(Animator))]; aligns spine yaw to the camera.

Demo & Editor code (not part of the runtime API)

Demo (Project/Scripts/Player/Demo/): PlayerEventLogger (implements both listener interfaces; copy it as a template), PlayerDropSystem, PlayerInventory, PlayerInteraction, WorldItem. Editor: custom inspectors plus the setup wizards; Tools ▸ First Person ▸ Setup Wizard, the Item Container setup, and the FPCutter Wizard.

Easy FP Full Body Controller is available as a paid asset in the Asset Store.

View on Asset Store ↗

Interfaces

PlayerController: the hub

Subsystem accessors

State (read-only)

Control methods (menus / cutscenes / pausing):

Configuration: PlayerSettings

Input: PlayerInputHandler

Per-frame state (read-only)

Methods

Player action map (FBInputActions)

Locomotion: PlayerLocomotion

Configurable fields

State

Camera: PlayerCameraController

Configurable

Public API

Items

HandItemSocket: canonical equip event source

Properties

Methods

ItemContainer: orchestration

Properties

Methods

Event

ItemHoldData: per-item config & reactions

ItemAttachmentData: hold & IK config

ItemIKPreset: share IK config

Event API: PlayerEventAPI

Event payloads

Item events: HandItemSocket

Locomotion events: PlayerLocomotion

Listener interfaces

Subscribe in code

FPCutter: FPCutterController

Methods

Config

Animator: PlayerAnimatorController

Procedural IK (advanced)

PlayerHeadIK

PlayerHandIK

PlayerSpineStabilizer

Player action map (`FBInputActions`)

Item events: `HandItemSocket`

Locomotion events: `PlayerLocomotion`
